| DECIMAL FACTOR PREFIXES |
| FACTOR |
PREFIX |
SYMBOL |
|
FACTOR |
PREFIX |
SYMBOL |
| 1018 |
exa |
E |
|
10-1 |
deci |
d |
| 1015 |
peta |
P |
|
10-2 |
centi |
c |
| 1012 |
tera |
T |
|
10-3 |
milli |
m |
| 109 |
giga |
G |
|
10-6 |
micro |
m |
| 106 |
mega |
M |
|
10-9 |
nano |
n |
| 103 |
kilo |
k |
|
10-12 |
pico |
p |
| 102 |
hecto |
h |
|
10-15 |
femto |
f |
| 101 |
deka |
da |
|
10-18
|
atto |
a |
|
| |
RESISTOR COLOR CODES
|
| COLOR |
VALUE OF |
| (1st & 2nd bands) |
(3rd band) |
(4th band) |
| Black |
0 |
0 |
±20% |
| Brown |
1 |
1 |
±2% |
| Red |
2 |
2 |
|
| Orange |
3 |
3 |
|
| Yellow |
4 |
4 |
|
| Green |
5 |
5 |
|
| Blue |
6 |
6 |
|
| Violet |
7 |
7 |
|
| Gray |
8 |
8 |
|
| White |
9 |
9 |
|
| Gold |
|
-1 |
±5% |
| Silver |
|
-2 |
±10% |
| No Color |
|
|
±20% |
|
| |
STANDARD RESISTOR VALUES
|
| 1.0 |
1.1 |
1.2 |
1.3 |
1.5 |
1.6 |
| 1.8 |
2.0 |
2.2 |
2.4 |
2.7 |
3.0 |
| 3.3 |
3.6 |
3.9 |
4.3 |
4.7 |
5.1 |
| 5.6 |
6.2 |
6.8 |
7.5 |
8.2 |
9.1 |
|
